Schneider Electric 9012GCR23

Schneider Electric 9012GCR23 by Square D by Schneider Electric

$
1,640
15
/ EA / 1 EA
  • Part Number: 9012GCR23
  • UPC: 00785901955054
  • Availability:
Quantity:
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Square D™ 9012GCR23 Single Stage Electromechanical Pressure Switch, 170 to 5600 psi Pressure, 578 to 1260 psi Differential, 2(NC-NO), DPDT-DB (Isolated) Contact, Screw Clamp Connection
Specifications
Details
Category Level 1:
Industrial Control
Category Level 2:
Pressure Controls
Category Level 3:
Pressure Control Switches
Connection Material:
PTFE/FKM Fluorocarbon/440 Stainless Steel/303 Stainless Steel
Connection Type:
Screw Clamp
Contact Configuration:
2(NC-NO), DPDT-DB (Isolated)
Diaphragm Material:
FKM Fluorocarbon
Differential:
578 to 1260 psi
Dimensions:
7.13 in W x 5.34 in D x 8.02 in H
Enclosure Type:
NEMA 7/9
Housing Material:
Cast Aluminum
Maximum Pressure:
20000 psi
Operating Cycles:
120 cpm
Pressure Rating:
170 to 5600 psi
Series:
9012G
Temperature Rating:
-10 to 185 deg F
Type:
Single Stage
Additional Information
Manufactured By:
Square D by Schneider Electric
