Ferraz Shawmut HelioProtection® HP10M12-V Type gPV Fast Acting Photovoltaic Fuse With Tab, 12 A, 1000 VDC, 10 kA, Class Midget, Cylindrical/Microfuse Body

Specifications

Details

Category Level 1:

Solar & Renewable Energy

Category Level 2:

Solar Distribution

Category Level 3:

Solar Fuses

Amperage Rating:

12 A

Application:

For PV string/array level protection, combiner box applications, In-line PV module protection, inverters battery charge controllers and string protection

Body Size:

0.41 in Dia x 1.5 in L

Body Type:

Cylindrical/Microfuse

Category Name:

Solar Fuses

Class:

Midget

Country:

USA/Canada

Element:

Single

Indicating/Non-Indicating:

Non-Indicating

Interrupt Rating:

10 kA

Length:

2.0

Material:

GMG

Mounting Type:

Clip

Rejection/Non-Rejection:

Non-Rejection

Series:

HP10M

Short Circuit Current Rating:

50 kA

Standard/Approvals:

RoHS Compliant|UL 2579 File No. E333668|CSA C22.2 Class 1422-30, 1422-03 File No. 012636_0_000|IEC 60269-6|CE Certified

Terminal Type:

Blade

Type:

Type gPV Fast Acting

Unspsc:

39121627

Voltage Rating:

1000

1000 VDC

Volume:

0.0

Weight:

0.0

Additional Information

Manufactured By:

MERSEN
